| Function |
KS-6215Z |
KS-6215Z- Plus |
| Processor |
VIA C7 1.5GHz |
| Memory |
512MB DDR2 400/533 SODIMM socket *1 ,Max 1G |
| Power Supply |
+12 V DC power adaptor, 80 W |
| Housing |
Aluminum die casting |
| Front bezel |
Textured |
| Base Stand |
Slim base |
| Speaker |
Built-in |
| OS Support |
Dos, Windows CE / Windows XP Pro / WEPOS, Linux |
| Safety Certifications |
FCC-A, CE-A, RoHS, WEEE |
| Display |
| LCD |
15” LCD, 200 nits, 1024X768 |
| Touch Sensor |
Resistive type |
| Touch Controller |
USB interface mouse emulation |
| Brightness Control |
Hardware VR control or software control |
N/A |
| Tilt Adjustment |
From 15° to 70° |
| Expansion |
| Storage Device |
2.5” 40GB HDD or optional CF memory card |
| Mounting option |
Desktop or wall mount |
| Connectivity |
| Audio Port |
2 Watts audio amplifier with internal speaker Mic. in/line out ports in KP-300 option |
| CR Port |
N/A |
1 x |
| KB Port |
1 x, P/S II |
N/A |
| LAN Port |
1 x, 10/100 Base T Ethernet, upgradeable to 1 G bps |
| Parallel Port |
1 x, SPP / EPP / ECP |
| Serial Port |
4x 10 pin RJ45, each with +5V power supply capability |
2 x DB9, with + 5 / +12 V power supply capability |
| UPS Port |
1 x, battery health auto-check |
| USB Port |
4 x, USB 2.0 + 1 proprietary port for SD-400 |
| Physical Dimension |
Dimension
(W x D x H) |
LCD@15°:378x304x364mm(12.5”x12.0”x14.3”)
LCD@70°:378x304x274mm(12.5”x12.0”x10.8”) |
LCD@15°:378x308x359mm(14.9”x12.1”x14.1”)
LCD@70°:378x297x283mm(14.9”x11.7”x11.1”) |
| Weight (N. W.) |
9.3kg(20.5 lbs) |
9.1kg(20.1 lbs) |
| Environment |
| Operation Condition |
0°C~+35°C (32°F~+104°F), 20%RH~80%RH, non-condensing max. wet bulb 26°C (78.8°F) |
| Storage Condition |
-20°C~+60°C (-4°F~+140°F) without UPS battery, -20°C~+40°C (-4°F~+104°F) with UPS battery, 10%RH~80%RH, non-condensing max. wet bulb 28.9°C (84.0°F) |
| Optional Attachment |
| 2nd HDD |
IDE 2.5” HDD 40GB in main unit |
2.5” SATA HDD in base |
| 2nd LCD Display |
12” LM-6101B; 15” LM-6301B, VGA port |
| Customer Pole Display |
PD-2501:11 mm 2 x 20 VFD display, 5X7 dot matrix, RS232 interface
PD-2602: 9 mm 2 x 20 VFD display, 5X7 dot matrix, default RS232 interface, optional USB interface
PD-306U: 2 x 20 LCD display, USB interface |
| Preloaded OS |
Windows XP Pro / WEPOS / Windows CE.NET / Linux |
| SD-400 / SD-400Z |
Optional MSR and/or finger print sensor in USB interface,SD-400(UV coating bezel) / SD-400Z (Textured bezel) |
| UPS Battery |
2.3 Ahr / 12 V, in base stand |
| Wireless LAN |
IEEE 802.11 b/g, USB interface, dongle exteral type |
