Specifications |
PB-4200 |
|
Processor |
Celeron 2.0 GHz (upgradeable to P4 2.4 GHz) |
|
Memory |
DDR266/333 256 MB
(expandable to 2 GB in 2 modules) |
|
VGA Memory |
Maximum 128 MB programmed by software |
|
Expansion |
|
PCI slot |
1x |
|
Condition (1) |
PCI slot is occupied & not available while Powered USB control card or 24V Powered board is installed |
|
Condition (2) |
PCI slot is available for use while Powered USB control card or 24V Powered board is not installed |
|
Hard disk drive (Ultra DMA) |
40 GB or above |
|
2nd HDD |
2.5”, Optional |
|
Power management kit |
Optional |
|
Main features |
1.Power-off prevention software
2.Uninterrupted power system (UPS) control
3.CR port control |
|
UPS Battery |
Optional |
|
Connectivity |
|
Powered USB Ports (12V/24V powered) |
Proprietary control card, optional |
|
24V Powered Port
(24V powered) |
1x, Option |
|
USB Ports |
3 X |
|
RS232 ports |
4 X |
|
VGA port |
1 X |
|
CF slot |
Optional |
|
Stereo audio line out / mic in |
YES |
|
Ethernet 10/100 (ONBOARD LAN) |
1 X |
|
Parallel port |
1x |
|
PS/2 KB & MOUSE |
YES |
|
Cash drawer port (CR port) |
1x, option (included in power management kit) |
|
Operating systems |
Win 2000 / XP Professional / WEPOS |
|
Color options |
Black / Ivory white |
|
Physical Dimensions |
|
Overall Dimensions |
279mm(W) x 244mm(D) x 113mm(H) (11.0”x9.6”x4.4”) |
|
Weight |
3.6 kg (7.9 lbs) |
|
Electrical requirements |
Switching power supply: Input 115/230V,
output DC 180W |
|
Safety certifications |
PSU: UL / TUV mark Terminal: FCC, CE (class A) |
|
Optional peripherals |
|
SD-300 |
USB Interface. 2-in-1 MSR and finger print sensor; MSR is UPOS 1.8 compliant. (MSR /FP Optional) |
|
BC-300 |
Bar Code card reader, USB interface |
|
KP-200 |
36 key dynakey with keylock attachment, optional: MSR, Smart card reader |
|
LM-2010 |
10.4” color LCD TFT |
|
PD-2601 |
2x20 VFD customer display, 5x7 dots matrix RS232 interface default (USB interface optional) |
|
PD-307 |
2x20 LCD customer display, 5x7 dots matrix RS232 interface default (USB interface optional) |
