处理器 - Type:Via 800Mhz VIA C3 processor
- 133/100Mhz FSB
芯片组 - North Bridge:VIA CLE266 Digital Media IGP Chipset.
- South Bridge:VIA VT8235M
系统内存 -1 DDR DIMM sockets. (266MHZ)
-UP to 1GB memory size.
显示核心 - Integrated VIA UniChrome IGP graphics
-64/32/16Mb shared system memory.
- Hardware MPEG-2 decoding acceleration
-AGP interface
扩展槽- 1 PCI slot
板载IDE - 2 UltraDMA 133/100/66 Connectors
板载网络 - 10/100Mbps RealTEK RTL8100C
板载声卡 - AC97 CODEC: ALC655.
Super I/O - ITE Super I/O
后面板输入/输出接口 The motherboard has a full set of I/O ports and connectors:
- Two PS/2 ports for mouse and keyboard
- 1 COM(serial) port
- 1 VGA port (D-SUB 15-PIN)
- One parallel port
- 1 RJ-45 LAN port
- 4 USB 2.0 port
- 2 Audio jacks for microphone and line-out
- ATX power connector
板载板输入/输出 - 1 COM2 (serial) port
- 2 USB 2.0 port
- 1 IR port
- 1 S/PDIF header
- 1 Front-panel audio connector (mic and line out)
- 1 Buzzer
BIOS - Award BIOS
- 256KB(2Mbit) flash ROM
系统监控及管理软件 - CPU voltage monitoring
- Wake-on-LAN, Keyboard Power-on, Timer Power-on
- System power management
- AC power failure recovery
支持操作系统 - Microsoft? Windows? 2000/XP
- Linux
运作温度 0~45°C
运作湿度 0% ~ 93% (relative humidity; non-condensing)
产品尺寸 - Mini-ITX
- 17 cm x 17 cm
